Large Format Slab Cutter DB-3 Upgrade | Upgraded| Perfect for Large Slab Cutting Projects

Categories	Large Format Slab Cutter
Brand	TILER tile cutting and laying tools distrubutor
Model	DB-3
Material	Aluminum profile
Max. cutting length	3200mm and more
Max. cutting thickness	12mm
Type	Straight cut
Size of scoring wheel	22mm
Handle type	Push handle
Fixed type	Built-in suction cup
Application	For cutting large-sized stone slabs
Download
Update Time	Dec 22,2024

Contact Now

Favorites

Detail Information

◢ SPECIFICATION

ART	QTY/INNER BOX	QTY/OUTER BOX
DB-3	/	1PC

◢ DESCRIPTION

TILER Large Format Slab Cutter DB-3 Cut Up to 3200mm and more Aluminum alloy guide rails, push handle ,tungsten carbide scoring wheel , factory price, wholesale

Designed specifically for cutting large-sized stone slabs, suitable for various dimensions such as 60x120cm, 75x150cm, 120x120cm, 150x150cm, 150x300cm, 160x320cm, 180x360cm, and more.
Crafted from premium aluminum alloy, it ensures lightweight construction and convenient portability.
Cutting thickness ranges from 4mm to 12mm.
Single guide rail enables cutting up to 120cm without the need for additional assembly.
Guide rails can be flexibly combined to accommodate different dimensions.
Extended ergonomic handle for comfortable and effortless operation.
Built-in suction cups on the guide rails eliminate the hassle of attaching separate suction devices, providing secure adhesion to the material being cut.
High-quality bearing wheels enable cutting lengths of up to 2000 meters and facilitate easy replacement.
Convenient nylon carrying bag for storage and easy transportation.

◢FAQ

What are the dimensions of stone slabs that the TILER Large Format Slab Cutter DB-3 can cut?

The TILER Large Format Slab Cutter DB-3 is designed to cut various dimensions of stone slabs, including sizes such as 60x120cm, 75x150cm, 120x120cm, 150x150cm, 150x300cm, 160x320cm, 180x360cm, and more.

What is the maximum cutting thickness of the TILER Large Format Slab Cutter DB-3?

The TILER Large Format Slab Cutter DB-3 can cut stone slabs with a thickness ranging from 4mm to 12mm.

Can the guide rails be adjusted to accommodate different dimensions?

Yes, the guide rails of the TILER Large Format Slab Cutter DB-3 can be flexibly combined to accommodate different dimensions of stone slabs.

How long of a cut can be made without additional assembly?

With its single guide rail design, the TILER Large Format Slab Cutter DB-3 enables cutting up to 120cm without the need for additional assembly.

Does the cutter come with suction cups for secure adhesion to the material being cut?

Yes, the TILER Large Format Slab Cutter DB-3 has built-in suction cups on the guide rails, eliminating the hassle of attaching separate suction devices. These suction cups provide secure adhesion to the material being cut.

How long can the cutting lengths be with the TILER Large Format Slab Cutter DB-3?

The TILER Large Format Slab Cutter DB-3 is equipped with high-quality bearing wheels that enable cutting lengths of up to 2000 meters. Additionally, these bearing wheels facilitate easy replacement.
